Ensure continued operation of critical devices with the CyberPower PDU24005 Metered ATS PDU. Ideal for data centers and network closets, this unit provides power redundancy to single-corded connected equipment. If power for the primary source exceeds the lower or upper thresholds, or if power fails, the PDU will switch to the secondary power source to ensure continuous operation. The PDU will switch back to the primary power source when incoming power becomes stable.
The PDU24005 supports inputs between 200-240V and includes (8) IEC C13 and (2) IEC C19 outlets. Dual IEC C20 power cords are plugged into separate power sources (A and B), and information about each power source is provided via LED indicator lights on the front of the unit. Other features include an LCD with selectable background color, ugradeable firmware, and network-grade plugs and outlets. The CyberPower PDU24005 is protected by a three-year limited warranty.
- General Information
- Manufacturer
- CyberPower Systems, Inc
- Manufacturer Website Address
- https://www.cyberpower.com/au
- Brand Name
- CyberPower
- Product Series
- Metered ATS PDU
- Product Type
- PDU
- Technical Information
- PDU Type
- Metered Auto Transfer Switch
- Phase
- Single Phase
- Plug/Connector Type
- IEC 60320 C20
- Plug/Connector Detail
- 2 x IEC 60320 C20
- Receptacle Type
- IEC 60320 C13
- IEC 60320 C19
- Receptacle Detail
- 8 x IEC 60320 C13
- 2 x IEC 60320 C19
- Protection Type
- Overload Protection
- Circuit Breaker
- Locking Receptacles
- Cord Retention Tray
- IEC 60320 C13
- IEC 60320 C19
- Features
- LCD Display
- LED Status Indicator
- Power Description
- Input Voltage
- 230 V AC
- Input Voltage Range
- 200 V AC - 240 V AC
- Output Voltage
- 230 V AC
- Output Voltage Range
- 200 V AC - 240 V AC
- Input Current
- 20 A
- Input Frequency
- 60 Hz
- Circuit Breaker
- Yes
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Product Material
- Metal
- Mounting Orientation
- Horizontal
- Mount Type
- Rack-mountable
- Form Factor
- Rack
- Rack Height
- 1U
- Cord Length
- 3.05 m
- Height
- 44 mm
- Width
- 433 mm
- Depth
- 215 mm
- Weight (Approximate)
- 3.45 kg
- Environmental Conditions
- Minimum Operating Temperature
- 0°C
- Maximum Operating Temperature
- 45°C
- Minimum Storage Temperature
- -15°C
- Maximum Storage Temperature
- 55°C
- Miscellaneous
- Additional Information
- Physical Dimensions - (WxHxD) (cm) : 43.31 x 4.45 x 21.46 (cm)
- Physical Dimensions - (WxHxD) (in) : 17.05 x 1.75 x 8.45 (in)
- Physical Dimensions - (WxHxD) (mm) : 433 x 44 x 215 (mm)
- Weight (kg) : 3.45
- Weight (lb) : 7.6
- Shipping Dimensions - (WxHxD) (cm) : 54.99 x 12.45 x 39.8 (cm)
- Shipping - Dimensions (WxHxD, in) : 21.65 x 4.9 x 15.67 (in)
- Shipping - Dimensions (WxHxD, mm) : 549.91 x 124.46 x 398.02 (mm)
- Shipping - Weight (kg) : 6.28
- Shipping - Weight (lb) : 13.84
- Cord Length : 10 ft (3.0 m)
- Derated Input Current : 16 A
- Input Frequency Range : 50 Hz - 60 Hz
- Input Overload Protection : 20A x 2
- Input Plug Type : 2 x IEC-320 C20
- Maximum Input Current : 20A
- Nominal Input Voltage : 240 - 200 VAC
- Phase : Single Phase
- Plug Style : Straight (Socket)
- Nominal Output Voltage : 240 - 200 VAC
- Outlet Banks : 1
- Outlets - Total : 10
- Outlet Type COMPUTED : 8 - IEC-320 C13
- Overload Protection : None
- Power Source Transfer Time : 2-7 ms
- Source Failure Detection Time : 2-3 ms
- Total Transfer Time : <10 ms
- Hardware Connection Port : Serial (RJ45)
- LCD : Multifunction LCD
- LED Indicators : Source Status
- Upgradeable firmware : Yes
- Color : Black
- Cord Retention Tray/Cord Organizers : Yes
- External Site Ground Pin : Yes
- Form Factors Supported : 1U Rackmount
- Material of Construction : Metal
- Rack Height : 1U
- Style : Rackmount
- Operating Elevation : 0 - 13123 ft (0 - 4000 m)
- Operating Relative Humidity : 0 - 95 % (non-condensing)
- Operating Temperature : 32 - 113 °F (0 - 45 °C)
- Storage Elevation : 0 - 49213 ft (0 - 14999 m)
- Storage Temperature : 5 - 131 °F (-15 - 55 °C)
- Environmental : RoHS Compliant
- Safety : UL62368 : FCC Class A : cTUVus/CE/UKCA
- Extended Warranty Option : WEXT5YR-PDU1A
- Product Warranty : 3 Year Limited Warranty
- Application/Usage
- Data Center
- Network Closet
